The Sungrow MG6RL 6kW Hybrid Inverter is a high-performance, single-phase solar solution designed for modern residential energy systems. Combining solar generation, battery storage, and grid connectivity, it ensures reliable and uninterrupted power for your home.
With ultra-fast backup switching of less than 4ms, the inverter provides seamless power during outages. It supports up to 200% peak output for 10 seconds, making it ideal for handling heavy startup loads like air conditioners and pumps.
Featuring dual MPPT trackers and a wide voltage range (40V–425V), the MG6RL maximizes solar energy harvest while offering flexible system design. Advanced safety features such as AFCI protection, dual pressure relief, and surge protection ensure safe and stable operation.
The 4.3-inch touchscreen display, along with optional Wi-Fi and Ethern...
Smart integration with generators & microinverters
AFCI protection & dual pressure relief system
Natural convection cooling (silent operation)
IP65 rated for indoor & outdoor installation
4.3-inch LCD touchscreen display
Wi-Fi / Ethernet remote monitoring (optional)
Product Specifications
Type
hybrid solar inverter
phase
single phase
recommended max pv power
12,000 wp
max usable pv power
9,600 wp
max pv voltage
500 v
startup / min voltage
50 v / 40 v
rated pv voltage
360 v
mppt voltage range
40 – 425 v
mppt trackers
2
max pv input current
40 a (20 a per string)
battery type
lithium-ion
battery voltage range
40 – 60 v
max charge/discharge current
135 a
max battery power
6,000 w
rated power
6,000 w
max apparent power
6,000 va
rated voltage
220 / 230 / 240 v
voltage range
154 – 276 v
frequency
50 / 60 hz
power factor
> 0.99
thd
< 3%
Product Details
The Sungrow MG6RL 6kW Hybrid Inverter is a high-performance, single-phase solar solution designed for modern residential energy systems. Combining solar generation, battery storage, and grid connectivity, it ensures reliable and uninterrupted power for your home.
With ultra-fast backup switching of less than 4ms, the inverter provides seamless power during outages. It supports up to 200% peak output for 10 seconds, making it ideal for handling heavy startup loads like air conditioners and pumps.
Featuring dual MPPT trackers and a wide voltage range (40V–425V), the MG6RL maximizes solar energy harvest while offering flexible system design. Advanced safety features such as AFCI protection, dual pressure relief, and surge protection ensure safe and stable operation.
The 4.3-inch touchscreen display, along with optional Wi-Fi and Ethernet connectivity, allows real-time monitoring and easy system management. With natural cooling, IP65 protection, and compact wall-mounted design, this inverter is built for durability, efficiency, and convenience.
