The Sungrow SG125CX-P2 125kW On-Grid Inverter is a high-capacity, industrial-grade solar solution designed for large commercial and utility-scale applications. Delivering a powerful 125kW AC output and up to 98.5% efficiency, this inverter ensures maximum energy conversion and optimized system performance.
Equipped with 12 independent MPPT trackers, it offers exceptional flexibility for complex solar installations, enabling maximum energy harvest even with varying panel orientations. Its wide MPPT voltage range (180V–1000V) and support for high PV input power up to 175 kWp make it ideal for large-scale solar plants.
Built with advanced protection systems including AFCI (Arc Fault Circuit Interrupter), PID recovery, and Type I+II surge protection, the SG125CX-P2 ensures superior safety and reliability. The IP66-rated enclosure, C5 anti-corrosion rating, and smart forced a...
High efficiency up to 98.5% (Euro efficiency 98.3%)
12 MPPT trackers for maximum energy optimization
Supports up to 175 kWp PV input capacity
Wide MPPT voltage range (180V – 1000V)
Built-in AFCI for advanced fire protection
PID recovery function for improved panel performance
Type I+II surge protection for enhanced safety
Smart monitoring via Bluetooth, RS485, WiFi & Ethernet
IP66 rated for dust & water resistance
High corrosion resistance (C5 grade)
Smart forced air cooling system
Supports optimizer & RSD compatibility (optional)
Suitable for large commercial & industrial solar systems
Product Specifications
Type
on-grid (grid-tied) inverter
phase
three phase
recommended pv power
175 kwp
max. pv input voltage
1100 v
min. pv input / start voltage
180 v / 200 v
rated pv input voltage
600 v
mppt voltage range
180 – 1000 v
no. of mppts
12
max pv input current
360 a (30 a × 12)
max dc short circuit current
480 a (40 a × 12)
max current per dc connector
30 a
rated output power
125 kw
max ac output power
125 kva
max ac output current
181.1 a
rated ac voltage
3 / n / pe, 220 / 380 v – 230 / 400 v
ac voltage range
320 – 480 v
grid frequency
50 / 60 hz
thd
< 3%
Product Details
The Sungrow SG125CX-P2 125kW On-Grid Inverter is a high-capacity, industrial-grade solar solution designed for large commercial and utility-scale applications. Delivering a powerful 125kW AC output and up to 98.5% efficiency, this inverter ensures maximum energy conversion and optimized system performance.
Equipped with 12 independent MPPT trackers, it offers exceptional flexibility for complex solar installations, enabling maximum energy harvest even with varying panel orientations. Its wide MPPT voltage range (180V–1000V) and support for high PV input power up to 175 kWp make it ideal for large-scale solar plants.
Built with advanced protection systems including AFCI (Arc Fault Circuit Interrupter), PID recovery, and Type I+II surge protection, the SG125CX-P2 ensures superior safety and reliability. The IP66-rated enclosure, C5 anti-corrosion rating, and smart forced air cooling system make it highly durable in harsh environments.
With integrated smart monitoring via RS485, optional WiFi/Ethernet, and Bluetooth app support, users can easily monitor and control system performance in real time.
