Tense Liquid Level Electrode Relay Price in Pakistan Rs 1,530/-. The Tense SSE-10 Liquid Level Electrode Relay is a reliable and efficient solution for monitoring and controlling liquid levels in tanks and reservoirs. Designed to work with conductive liquids, it operates by detecting the presence or absence of liquid using electrode sensors. Ideal for water tanks, industrial processes, and pumping systems, the SSE-10 helps prevent overflow and dry running, ensuring automated and safe fluid management.
Automatically controls liquid levels in tanks using electrodes
CE certified and suitable for industrial and domestic applications
Compact DIN rail mount design for easy panel installation
High sensitivity range for various tank depths
LED indicators for power and relay output status
Long-lasting and maintenance-free operation
Prevents tank overflow and pump dry-run conditions
Quick response time for efficient level detection
Simple 3-probe configuration for reliable performance
Works with a wide range of conductive liquids (e.g., water)
Product Specifications
Type
electrode relay
model
sse-10
contact rating
5a / 250v ac
electrode type
conductive (3-electrode system
function
liquid level control via electrodes
housing material
flame-retardant plastic
led indicators
power and relay status
mounting type
din rail
operating temperature
-10°c to +55°c
output contacts
1 c/o (changeover) relay
protection class
ip20
response time
< 200 ms
sensitivity range
up to 100 ko
supply voltage
220v ac / 50-60 hz
Product Details
Tense Liquid Level Electrode Relay Price in Pakistan Rs 1,530/-. The Tense SSE-10 Liquid Level Electrode Relay is a reliable and efficient solution for monitoring and controlling liquid levels in tanks and reservoirs. Designed to work with conductive liquids, it operates by detecting the presence or absence of liquid using electrode sensors. Ideal for water tanks, industrial processes, and pumping systems, the SSE-10 helps prevent overflow and dry running, ensuring automated and safe fluid management.
