Terasaki AR316H 3P 1600A Air Circuit Breaker Fixed Mounting Type

Name: Terasaki AR316H 3P 1600A Air Circuit Breaker Fixed Mounting Type
Brand: Terasaki
SKU: AR316H-3P-1600A
Price: 1836000 PKR
Availability: OutOfStock

Product SKU:AR316H-3P-1600A

Rs.1,836,000 PKR

Sale Sold out

Product variants

About This Product

Key Features

Terasaki TemPower2 Air Circuit Breaker
3-Pole configuration
Fixed mounting type
Rated frame current: 1600A
Adjustable... Show All Key Features

Product Specifications

Product type	air circuit breaker
series	tempower2
poles	3 pole
mounting type	fixed

Product Details

The Terasaki TemPower2 AR316H 3-Pole Air Circuit Breaker is engineered to protect electrical systems exposed to extremely high short-circuit levels. Featuring a rated frame current of 1600A with an adjustable current setting range of 640A to 1600A, this ACB is ideal for main incomers, generator protection, and transformer feeders in heavy-duty power distribution networks.

With an extra high AC breaking capacity of 100kA at 440VAC, the AR316H delivers superior fault-clearing performance, ensuring equipment protection and uninterrupted system operation. Its LSIG electronic protection unit provides comprehensive coverage against overload, short-time, instantaneous, and ground faults.

Designed with a fixed mounting configuration and fully compliant with IEC 60947-2, the Terasaki AR316H offers Ics = 100% of Icu and Icw = 100% of Icu, guaranteeing full selectivity and excellent short-time withstand capability. Built-in trip memory and Terasaki’s proven engineering ensure long service life and dependable performance in mission-critical environments.
