Ziewnic LenoX 16kW PV20000 Three Phase Hybrid Solar Inverter
Availability: In Stock

Ziewnic LenoX 16kW PV20000 Three Phase Hybrid Solar Inverter

Product SKU: PV20000-16KW
Rs.640,000

Safe Delivery

Quick & safe nation wide delivery

Easy Return

Hassle free return within 7 days

100% Original Product

Only genuine products, no compromises.

 WhatsApp Inquiry

Specifications

Type Hybrid Solar Inverter
Rated Power 16000W
Maximum PV Input Power 20000W
Maximum DC Voltage 800V
MPPT Voltage Range 200V – 650V
Maximum Input Current 36A + 36A
Maximum Input Strings 2 + 1
Grid Voltage 230V / 400V (Three Phase)
Grid Frequency 50Hz / 60Hz
Power Factor 0.8 Lagging to 0.8 Leading
THDi <3%
AC Output Topology L + N + PE
Battery Voltage Range 40V – 63V
Maximum Charging Voltage 63V
Maximum Charge / Discharge Current 240A / 240A
Battery Type Lithium / Lead-Acid / Tubular
UPS Rated Power 16kW
Peak Power (Off Grid) 1.5 Times Rated Power for 10 Seconds
Three Phase Rated Output Current 42A
Rated Output Frequency 50Hz / 60Hz
Transfer Time <10ms
THDu <10%
Overload Capacity 5s >110% Load, 10s =101%–110% Load
Anti-Island Protection Yes
Insulation Monitoring Yes
Residual Current Monitoring Yes
Arc Fault Protection Optional
Parallel Function Yes, Multiple Units
Other Protection AC Over-Current, AC Over-Voltage, Over Temperature Protection
Peak Efficiency 99%
Operating Temperature -40°C to 60°C (>45°C Derating)
Cooling Method Smart Cooling
Relative Humidity 5% – 95% (Non-Condensing)
Altitude Above 2000m Derating
Dimensions (W × D × H) 446 × 486 × 256 mm
EMC/Safety Regulation IEC/EN 62109-1, IEC/EN 62109-2, IEC/EN 61000-6-2, IEC/EN 61000-6-4
Isolation Transformer Yes
Self-Consumption <5W
Display Touch Screen
Communication Interface RS232, CAN, RS485
Optional Communication WiFi, CT
Safety Standard EN/IEC 62109-1, EN/IEC 62109-2
Solar Charge Controller Current 240A
Zero Export Function Built-In

Key Features

High power motor
Higher work efficiency
Product Details Reviews Shipping & Returns

Ziewnic LenoX 16kW PV20000 Three Phase Hybrid Solar Inverter

The Ziewnic LenoX 16kW PV20000 Three Phase Hybrid Solar Inverter is a powerful commercial-grade energy storage solution designed for large residential, commercial, and industrial solar installations. Featuring advanced three-phase hybrid technology, dual MPPT tracking, and support for 48V LiFePO4, lead-acid, and tubular batteries, it delivers exceptional energy efficiency and system flexibility. With a massive 20kW PV input capacity, 240A charge/discharge current, built-in zero export functionality, and intelligent load management, the PV20000 maximizes solar utilization while ensuring reliable backup power. Its smart monitoring capabilities, generator support, and parallel operation make it an ideal solution for high-demand energy applications.
