Variable Frequency Drives or VFDs are widely used to control the speed of electric motors. They help save energy, reduce wear, and improve system performance. But like any electrical equipment, VFDs can develop problems over time. Knowing how to identify and fix common faults can help avoid long delays and costly repairs.
In this blog, we will go over some of the most common VFD faults and show you simple techniques to troubleshoot them. Understanding these problems can help you keep your machines running smoothly and safely.
Overvoltage Fault
This fault happens when the DC bus voltage inside the VFD goes higher than the limit set by the manufacturer. It often takes place during deceleration or when the motor is slowing down quickly. When this happens, the motor acts like a generator and sends energy back into the VFD.
To fix this, try reducing the deceleration time in the VFD settings. This allows the motor to slow down more gently. You can also install a braking resistor or a dynamic braking unit to absorb the extra energy and reduce the voltage rise.
Undervoltage Fault
An undervoltage fault occurs when the input voltage to the VFD drops below the minimum level. This can be caused by problems with the power supply or sudden drops in the electrical line.
To troubleshoot this, check the incoming voltage with a meter and make sure it matches the required input range for your VFD. Also inspect the power cables and connectors for damage or loose connections. If the voltage is stable and the fault keeps showing, the VFD’s power section may need to be checked.
Overcurrent Fault
This happens when the current flowing through the VFD or the motor is too high. It can be caused by short circuits, too much load on the motor, or sudden changes in speed.
Start by checking the motor and its wiring. Make sure there are no shorted or damaged cables. Look at the load connected to the motor and ensure it is not stuck or jammed. Also check the acceleration time in the VFD settings. A very short acceleration time can cause a sharp rise in current. Adjusting it can reduce the fault.
Overtemperature Fault
When a VFD gets too hot, it will shut down to protect itself. This can happen if the cooling fans are not working, if the air vents are blocked, or if the drive is placed in a hot or closed space.
First, clean the VFD and remove dust from the cooling fans and air vents. Check that the fans are running properly. Make sure the drive is installed in a place with good airflow. If possible, keep the room temperature low. If the drive still overheats, consider adding an external fan or moving the VFD to a cooler area.
Ground Fault
A ground fault takes place when current leaks from the motor circuit to the ground. It is often caused by damaged motor windings or worn insulation on cables.
To find this issue, disconnect the motor and test the cables for insulation resistance using a megohmmeter. If the reading is low, the cable or motor insulation may be damaged. Replace the faulty parts and reset the drive.
Communication Fault
Some VFDs are connected to a central system or controller using communication cables. A communication fault means the drive has lost contact with the controller.
Check the communication cables for breaks or loose connections. Make sure the settings for communication like address and protocol match with the controller. If needed, reset the system and recheck all cable connections.
Phase Loss Fault
This happens when one of the power supply phases is missing or weak. It can damage the motor and the VFD if not fixed quickly.
Use a multimeter to check the three-phase input. If one phase has a much lower voltage or no voltage at all, you may have a blown fuse or a loose wire. Fix the connection or replace the damaged fuse to restore normal operation.
Motor Stall or Lock Fault
This fault shows up when the motor cannot rotate properly. The load may be too heavy or there may be mechanical issues like a blocked shaft or seized bearing.
Turn off the power and inspect the motor and the machine it drives. Remove any objects that may be blocking movement. Also check the motor shaft by hand. If it is hard to turn, the motor may need service or replacement.
Basic Troubleshooting Tips
Start by writing down the fault code shown on the VFD display. Most drives show an error number or message that points to the cause. Refer to the user manual for a list of codes and what they mean.
Turn off the power before touching any wires or parts. Wait a few minutes to make sure all internal power has drained. Use insulated tools and wear safety gear during any inspection or repair.
Keep the VFD clean and cool. Dust and heat are major reasons for failure. Do regular checks on the fans, cables, and terminal connections. Make sure the drive is grounded properly to avoid false faults or electric shock.
If a fault keeps returning and all basic steps have been followed, the problem may be inside the VFD. In that case, contact a trained technician or the manufacturer’s service center.
Final Thoughts
Understanding common VFD faults helps reduce downtime and improve safety. Many issues can be fixed with basic checks and adjustments. Keep the VFD clean, monitor the load, and follow proper wiring and setup steps. Record any faults and repairs to help with future problems. With the right care, your VFD will provide long service and reliable motor control.
