extensively braced heavyweight fibreboard construction with internal damping panels and the introduction of a slot port to the AE1 design for the first time. With several AE models already benefiting from the company’s R&D programme into slot port loading, the AE1 Active’s port delivers unrivalled cross-sectional area, reduced baffle space and significantly reduced ‘wind-noise’ at high volumes.
The AE1 Active maximises all the benefits of active loudspeaker design. These include reducing crossover losses, eliminating speaker cable influences and delivering unrivalled dynamic power. The result is a cohesive active loudspeaker with performance rivalling passive speaker / external amplifier set ups at many times its price.
With a bandwidth from 40Hz to 25kHz, efficiency of 104dB for 1Vrms, and maximum SPL of 115dB, no other small speaker gets close to the AE1 Active’s performance.
The AE1 Active is equally comfortable in the home or the recording studio. With the added benefit of adjustable bass and treble and a choice of RCA or balanced XLR connections, this speaker blends seamlessly into any listening environment.
Legendary speakers – made active
Famous for their sound for over three decades, the AE1s are truly legendary speakers. Now available in active form, you’re not only saving space but also guaranteed amps that are perfectly matched to the speakers.
Hear the sound – precisely as it should be
Pioneering metal cone technology has meant these speakers did, and still do, sound incredibly precise and neutral. Dynamic and low in distortion, these speakers let you hear every last drop of detail – just as the artist intended.
Smooth, Class A/B amp
Each speaker is fitted with a dedicated, 50-watt Class A/B amplifier. This gives perfect balance and soundstaging between the speakers. The powerful amps also mean that room-filling, party pumping volumes are easy to achieve – even from these compact speakers. Individual bass and treble controls let you trim the sound to suit.
Studio compatible
Acoustic Energy’s studio heritage makes these speakers just as happy in a small studio as a home environment. Featuring pro-standard XLR balanced inputs and typically precise sound quality, the AE1 Active speakers make ideal monitors in small or travel studios.
Choice of luxury finishes
Available in Piano gloss black, white or real cherry wood veneer, the AE1 Active speakers look every bit as good as they sound. Slim profile, magnetically attached grilles are also included for a more discreet style.
Technical
• Drive Unit: 125mm ceramic aluminum sandwich cone
• Tweeter: 25mm aluminum dome
• Frequency Range: 42Hz - 28kHz +/-6dB
• Input Sensitivity: 104dB for 1VRMS @ 1kHz
• Peak SPL: 115dB
• Maximum SPL: 105dB
• Amplifier: Class A/B with linear power supply
• Power: 100w
• Crossover Frequency: 3.5kHz 4th Order Linkwitz-Riley
• Inputs: RCA and Balanced XLR
• Controls: Volume adjust 0dB to -inf, HF shelf +/-2dB, LF shelf +/-2dB
• Power Connection: IEC C13
• Voltage: Switchable 110 / 240v
• Safety Certification: CE EN55013/20
• Design: 2 way active
• Cabinet: 18mm MDF with bracing and damping panels
• Grilles: Slim, cloth magnetic fit
• Dimensions (mm): 300 x 185 x 250 (HxWxD)
• Weight: 18kg (pair)
