Range
|
compact new generation
|
|
device short name
|
nsxiooh
|
|
product or component type
|
circuit breaker
|
|
device application
|
distribution
|
This ComPacT NSX100H is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 70kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 16A, 25A, 40A, 63A, 80A, 100 rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and a fixed magnetic protection. This 3-pole version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX100H is part of Schneider Electric EcoStruxure Power architecture.
