Terasaki AR316H 3P 1250A Air Circuit Breaker Fixed Mounting Type

Name: Terasaki AR316H 3P 1250A Air Circuit Breaker Fixed Mounting Type
Brand: Terasaki
SKU: AR316H-3P-1250A
Price: 1656000 PKR
Availability: OutOfStock

Product SKU:AR316H-3P-1250A

Rs.1,656,000 PKR

Sale Sold out

Product variants

About This Product

Key Features

Terasaki TemPower2 extra high breaking capacity air circuit breaker
3-pole configuration for low-voltage power distribution
Fix... Show All Key Features

Product Specifications

Product type	air circuit breaker
series	tempower2
poles	3 pole
mounting type	fixed

Product Details

The Terasaki TemPower2 AR316H 3-Pole Air Circuit Breaker is engineered for electrical installations exposed to extremely high fault levels. Featuring a rated frame current of 1250A and an adjustable current setting range of 500A to 1250A, this ACB is ideally suited for main incomers, generators, and transformer feeders in high-capacity power networks.

With an extra high AC breaking capacity of 100kA at 440VAC, the AR316H ensures fast and reliable interruption of severe short-circuit faults, protecting both equipment and personnel. Its LSIG electronic protection unit provides complete protection against overload, short-time, instantaneous, and ground faults.

Designed with a fixed mounting type and manufactured in accordance with IEC 60947-2, the Terasaki AR316H offers Ics = 100% of Icu and Icw = 100% of Icu, ensuring full service continuity and exceptional short-time withstand strength. Built-in trip memory and Terasaki’s proven engineering make this ACB a trusted solution for mission-critical power distribution.
