24 × Gigabit RJ45 ports with PoE+ and 24V passive PoE
2 × 1G SFP uplink ports
1 × RJ45 Serial Console Port
Non-blocking throughput: 26 Gbps
Switchi...
Show All Key Features
Ubiquiti UniFi Switch 24-Port PoE-250W Price is on Inquiry/-. The Ubiquiti UniFi US-24-250W is a fully managed 24-port PoE+ Gigabit switch designed for high-performance networking. Featuring twenty-four 10/100/1000 Mbps RJ45 ports and two 1G SFP uplink ports, this Layer 2 switch supports both IEEE 802.3af/at PoE+ and 24V passive PoE to power a wide range of UniFi devices. It delivers a non-blocking throughput of 26 Gbps and a switching capacity of 52 Gbps, allowing seamless traffic flow without packet loss. Ideal for scalable enterprise networks, the US-24-250W also features intelligent switching, comprehensive management options, and silent fan control levels for minimal acoustic impact. Built to be rack-mounted and engineered with internal 250W AC/DC power, it ensures efficient and reliable network performance.
24 × Gigabit RJ45 ports with PoE+ and 24V passive PoE
2 × 1G SFP uplink ports
1 × RJ45 Serial Console Port
Non-blocking throughput: 26 Gbps
Switching capacity: 52 Gbps
Forwarding rate: 38.69 Mpps
Supports IEEE 802.3af/at PoE+ and 24V Passive PoE
Max PoE+ per port: 34.2W | Passive PoE: 17W
Internal 250W AC/DC power supply
Fan-controlled cooling with quiet operation
1U rack-mountable design
Product Specifications
Type
unifi switch
dimensions
485 x 43.7 x 285.4 mm
weight
4.7 kg
rackmount
1u
ports
24× rj45 (gigabit), 2× sfp (1g), 1× serial
throughput
26 gbps
switching capacity
52 gbps
rate
38.69 mpps
poe
802.3af/at & 24v passive
max/port
34.2w (poe+), 17w (passive)
power
internal 250w ac/dc
consumption
max 250w
leds
rj45 & sfp – poe, speed, activity
environment
temp
humidity
5–95%
noise
9.1–21.2 dbr
protection
±24 kv esd/emp
certifications
ce, fcc, ic
Product Details
Ubiquiti UniFi Switch 24-Port PoE-250W Price is on Inquiry/-. The Ubiquiti UniFi US-24-250W is a fully managed 24-port PoE+ Gigabit switch designed for high-performance networking. Featuring twenty-four 10/100/1000 Mbps RJ45 ports and two 1G SFP uplink ports, this Layer 2 switch supports both IEEE 802.3af/at PoE+ and 24V passive PoE to power a wide range of UniFi devices. It delivers a non-blocking throughput of 26 Gbps and a switching capacity of 52 Gbps, allowing seamless traffic flow without packet loss. Ideal for scalable enterprise networks, the US-24-250W also features intelligent switching, comprehensive management options, and silent fan control levels for minimal acoustic impact. Built to be rack-mounted and engineered with internal 250W AC/DC power, it ensures efficient and reliable network performance.
