Schneider Electric

Schneider CVS400N 3 Pole 400A Molded Case Circuit Breaker

Name: Schneider CVS400N 3 Pole 400A Molded Case Circuit Breaker
Brand: Schneider Electric
SKU: LV540511
Price: 215000.0 PKR
Availability: InStock

Product SKU:LV540511

Be the first to review

Rs.215,000.00 PKR

Sale Sold out

people bought this recently

Product variants

About This Product

Key Features

Range: EasyPact
Product name: EasyPact CVS
Device short name: CVS400N
Weight: 6.3 kg
Product or component type: Circ... Show All Key Features

Product Specifications

Range	easypact
product name	easypact cvs
device short name	cvs400n
product or component type	circuit breaker

Product Details

Schneider CVS400N 3P MCCB Breaker price in Pakistan is Rs 215,000/-.

EasyPact CVS400N is a 4 poles 4d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized building protection applications. The breaking capacity (Icu) is 50kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds an electronic ETS 2.3 trip unit, with a 400A rating. ETS 2.3 trip unit provides adjustable long-time and short-time protections and fixed instantaneous protection. This 4-pole version (185mm x 255mm x 110mm) comes with a variety of optional functions and accessories. EasyPact CVS400N is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in class II insulation switchboards as it is a class II front-face de...

User Manual

Schneider CVS400N 3 Pole 400A Molded Case Circuit Breaker.pdf

Powerhouse Benefits

Invoice Available
Secure Payments
365 Days Help Desk

Return & Warranty Policy

Upto 3 Days Returnable
Missing Product
Wrong Product
Damaged Product

Schneider CVS400N 4 Pole MCCB Breaker 36KA Price in Pakistan

Looking to purchase Schneider CVS400N 3 Pole 400A Molded Case Circuit Breaker in bulk?

Purchase item in bulk quantity
Get at best price for your business

Reviews & Ratings

Update Qty

Related Categories

Circuit breakers Industrial automation & circuit protection Molded case circuit breakers Schneider electric

Range	easypact
product name	easypact cvs
device short name	cvs400n
product or component type	circuit breaker
device application	distribution
poles description	3p
weight	6.3 kg
protected poles description	3d
earth leakage protection (vigi add-on)	without
rated current [in]	320 a at 40 °c
network type	ac
utilisation category	category a
breaking capacity [icu]	50ka
trip unit name	ets 2.3
trip unit technology	electronic
trip unit rating	400 a at 40 °c
protection type	overload protection (thermal) / short-circuit protection (magnetic)
rated impulse withstand voltage [uimp]	Short time short-circuit protection / instantaneous short-circuit protection / overload protection (long time)
network frequency	50/60 hz
breaking capacity code	n
mechanical durability	15000 cycles
electrical durability	6000 cycles 415 v in conforming to iec 60947-2
control type	toggle
long-time pick-up adjustment type ir	adjustable 9 settings
long-time pick-up adjustment range	160…400 a
long-time delay adjustment type	fixed
instantaneous pick-up adjustment type ii	fixed
instantaneous pick-up adjustment range	11 x in
contact position indicator	yes
mounting mode	fixed
mounting support	backplate
upside connection	front
downside connection	front
standards	en 60947-2 / iec 60947-2
electrical shock protection class	class ii
pollution degree	3 conforming to iec 60664-1
ip degree of protection	ip40
ambient air temperature for operation	-25…70 °c
ambient air temperature for storage	-50…85 °c
